Features:
1.6/8/12/16 Mono Microphone Input
2.Each channel has -20dB attenuation fareasy adjustment of music quality
3.The newclassical “British style” 3-band equalizer creates warm sound
4.With auxiliary send, auxiliary return function
5.Dual channel independently controlled-band EO
6.Use 16 kinds of digital display effects, so that the sound is particularly pleasant, suitable for a variety of scenes to use
7.With display MP3 player, beautiful design, excellent sound quality
8.Built-in protection function complete power powerful power amplifier
| Model | MX608D | MX808D | MX1208D | MX1608D |
| Line Channel | 6 | 8 | 12 | 16 |
| Channel EQ | 3 BAND | |||
| AUX Output | 2 | |||
| Return | 1 | |||
| EFFECT | 16 effect | |||
| Main EQ | 7 BAND | |||
| Main OUT | 1 Stereo | |||
| Phantom Power | 48V DC | |||
| Total harmonic distortion | < -0.1 % | |||
| Frequency response | 20Hz-20KHz +1 dB /-3dB | |||
| S/N | -75db | |||
| Resi dual output noise | <-80dBu | |||
| Gain control | MIC 35dB(20dB-60dB) Line 20dB(20dB-60dB) | |||
| Power consumption | / | |||
| Hea dphone output power | 150mW(1 KHz,THD=0.5%,200 Ω | |||
| Maximum output level | 18dBm(1KHz,THD=0.5%) | |||
| Power amplifier output maximum power | 350W (4ΩX2) | |||
