Features:
1.Balanced microphone
2.Provides high quality + 48V phantom power
3.High and low bass classical balance, create a warm tone
4.Take a group of lotus output
5.Stereo 7-band graphic equalizer,assigned to the mainline
6.16/99 kinds of reverberation effect with double display,making the sound particularly pleasant
7.Built-i quality MP3 player, excellent sound quality
8.All channels have peak signal indication and pre-fader monitor selection
9.Built-in protection function complete power powerful power amplifier
| Model | TA4 | TA6 | TA8 | TA12 | TA16 |
| Line Channel | 4 | 6 | 8 | 12 | 16 |
| Channel EQ | 3 BAND | ||||
| AUX Output | 2 | ||||
| Return | 1 | ||||
| EFFECT | 16/99 effect | ||||
| Main EQ | 5 BAND | ||||
| Main OUT | 1 Stereo | ||||
| Phantom Power | 48V DC | ||||
| Total harmonic distortion | < -0.1 % | ||||
| Frequency response | 20Hz-20KHz +1 dB /-3dB | ||||
| S/N | -75db | ||||
| Resi dual output noise | <-80dBu | ||||
| Gain control | MIC 35dB(20dB-60dB) Line 20dB(20dB-60dB) | ||||
| Power consumption | 2x200W/2 x350W | ||||
| Hea dphone output power | 150mW(1 KHz,THD=0.5%,200 Ω | ||||
| Maximum output level | 18dBm(1KHz,THD=0.5%) | ||||
| Power amplifier output maximum power | 200W (4ΩX2) /350W (4ΩX2) | ||||
