Features:
1.Balanced microphone
2.Provides high quality+ 48V phantom power
3.High and low bass classical balance, create a warm tone
4.With a set of recording lotus output, CD input control
5.Stereo 7-band graphic equalizer, assigned to the mainline
6.16/99 with two-digit display reverb effects, including reverb, chorus, delay, transposition, multiple effects, beat function
7.Built-in quality MP3 player, excellent sound quality, Bluetooth transm1ss1on
8.All channels have peak signal indication and pre-fader monitor selection
9.Built-in protection function complete power powerful power amplifier
| Model | YA4 | YA6 | YA8 | YA12 |
| Line Channel | 4 | 6 | 8 | 12 |
| Channel EQ | 3 BAND | |||
| AUX Output | 2 | |||
| Return | 1 | |||
| EFFECT | 16/99 effect | |||
| Main EQ | 7 BAND | |||
| Main OUT | 1 Stereo | |||
| Phantom Power | 48V DC | |||
| Total harmonic distortion | < -0.1 % | |||
| Frequency response | 20Hz-20KHz +1 dB /-3dB | |||
| S/N | -75db | |||
| Resi dual output noise | <-80dBu | |||
| Gain control | MIC 35dB(20dB-60dB) Line 20dB(20dB-60dB) | |||
| Power consumption | 2x200W/2 x350W | |||
| Hea dphone output power | 150mW(1 KHz,THD=0.5%,200 Ω | |||
| Maximum output level | 18dBm(1KHz,THD=0.5%) | |||
| Power amplifier output maximum power | 2x200W/2 x350W | |||
